ET/GigFailover v2.0 (PCIe)

Two Gigabit Ethernet Copper Ports, 10/100/1000 BaseT, with Hardware Failover/Bypass

The ET/GigFailover is built on Intel's Gigabit technology; this card is best suited for systems with 4 or fewer CPU cores. The hardware Failover/Bypass function allows systems incorporating the ET/GigFailover to eliminate single point of failure concerns by bypassing the system in the event of a power down or software lockup or failure. Additional features allow a system with the ET/Gigfailover to be temporarily taken offline, allowing for safe upgrades or maintenance even from a remote location. A functional description of the bypass function can be found here

Features

• Intel's 82571GB controller
• Silicom Part# PEG2BPi
• Can act as 2 port card or bypass card
• Two integrated PHYs for 10/100/1000 Mb/s full and half-duplex operation
• Programmable Bypass - during power off or software failure
• PCI-Express Base Specification Revision 1.0a
• IEEE 802.3ab, 802.3u, 802.3x compliant
• Host offloading options - TCP/IP/UDP checksum, TCP segmentation and advanced packet filtering
• Two RJ45 Connectors

Software Support

This card can be used as a plug in solution with ET/BWMGR appliances or as a standalone solution with a software bypass driver. If you will not be using the card with an ET/BWMGR appliance or CD appliance, you must specify in the comments field that you need the software as its not normally included.

• FreeBSD, Linux
• Full Driver Module and Easy-to-use
• Cards are OEM encoded: Required for use with our Appliance Software

Dimensions

• Low profile PCI form factor (Low Profile Brackets on request with order)
• Length, 167.64 mm 6.6"
• Height, 64.41 mm 2.5"
